Building a Tailscale Subnet Router on AWS with Terraform

Today I finished a pretty fun challenge: building a Tailscale Subnet Router on AWS using Terraform. Infrastructure as Code from start to finish.

Let me walk you through it.

What I Built

Here's the AWS infrastructure I created:

• VPC with CIDR 10.1.0.0/16
• Public Subnet — where the Tailscale Subnet Router lives, with internet access through an Internet Gateway
• Private Subnet — where the Private EC2 lives, with no internet access at all
• EC2 Subnet Router — Ubuntu, Tailscale installed, IP forwarding enabled, UFW locked down
• EC2 Private — truly private, no public IP, no internet access

And the coolest part: I can access that Private EC2 from my laptop — just through Tailscale, using its internal AWS IP (10.1.x.x). No traditional VPN, no NAT Gateway, no public IP needed.

Architecture

It's actually pretty simple:

My Laptop → Tailscale → EC2 Subnet Router → AWS Private Network → EC2 Private

My laptop and the Private EC2 are connected through Tailscale. The Subnet Router acts as a bridge — it receives traffic from Tailscale and forwards it into the internal AWS network.

Workflow

Everything is written as Terraform code:

1. Terraform init — set up the AWS provider
2. Terraform apply — create all 13 resources
3. Auto-bootstrap — when EC2 boots, it automatically installs Tailscale, enables IP forwarding, and advertises the route
4. Approve route in Tailscale Admin Console — so subnet traffic can flow through
5. Test connectivity — ping, SSH, nc from laptop to Private EC2
6. UFW Lockdown — disable SSH access via public IP, only allow through Tailscale
7. Cleanup — terraform destroy, revoke auth key

Everything is automated except route approval and UFW lockdown.

Results

Everything went smoothly after deployment:

• ✅ Laptop can ping the Private EC2 (10.1.2.54)
• ✅ Laptop can SSH into the Private EC2 without a public IP
• ✅ Laptop can nc/telnet to the Private EC2's ports
• ✅ Subnet Router can access the internet (via IGW)
• ❌ Private EC2 cannot access the internet (as designed)
• ✅ After UFW lockdown, SSH via public IP is blocked, but via Tailscale it still works

Lessons Learned

A few things I picked up from this lab:

1. Source/Destination Check must be disabled — When an EC2 acts as a subnet router, AWS drops packets that aren't destined for the instance itself by default. You must set source_dest_check = false.

2. Never hardcode auth keys — Tailscale auth keys are sensitive. Store them in environment variables (TF_VAR_tailscale_auth_key), not in terraform.tfvars files that might get committed.

3. UFW is more flexible than Security Groups — SGs operate at the AWS level with limited control. UFW inside the VM gives you finer control: "allow SSH only from the Tailscale interface, block from the internet." Perfect for this kind of lab.

4. Routes need manual approval — Even when Tailscale shows as connected, the subnet route (10.1.0.0/16) still needs to be approved through the Admin Console. It's not automatic.

5. Ephemeral keys are a lifesaver — When the EC2 is destroyed, the device automatically leaves your Tailnet. No manual device cleanup needed.

Challenges Faced

• Auth key was logged out — Had to regenerate. Lesson: always check /var/log/user-data.log when something goes wrong.
• UFW lockdown timing — Wasn't sure when to enable UFW. The answer: do it after all tests pass, so you can still troubleshoot via public IP.
• Test script uses public IP — Once UFW was active, test-connectivity.sh failed because it connects via public IP. Solution: test manually through the Tailscale IP.

Conclusion

This lab proves that:

You can access an EC2 in a Private Subnet without a public IP, NAT Gateway, or traditional VPN — just using Tailscale Subnet Router.

Infrastructure is fully automated with Terraform. Bootstrapping happens automatically on first boot. And the security model works: after UFW lockdown, public SSH is blocked, but Tailscale access keeps working.

Repository: https://github.com/stayrelevantid/tailscale-aws
